37
EN
4. Tighten the right and left hand grips on the handle bar. Ensure appropriately
marked hand grips are being tightened into the slots. The hand grip marked
‘R’ should be xed on the right side and the one marked ‘L’ on the left side.
The hand grips do not t into opposite slots.
5. Loosen the lock buckle of the extendible steering column to adjust it to the
required height.
6. Press the metal pin (A) and pull the extendible steering column to the
required height (B). The metal pin should “click” back in place.
A
B
CB0049-BigTrend-IM-INT-V1.2.indb 37 20/12/2018 10:56 AM
