3 Straw discharge
3.1 Chaff spreader
82706
Pos. M
A
(Nm)
Auxiliary utilities Remarks
1 - 8 Multi-purpose grease, e.g.:
CLAAS AGRIGREASE EP 2,
Part no. 00 0147 437 0
Solid lubricant, e.g.:
MOLYKOTE G-n plus
Part no. 00 0177 571 0
– Adjusting the torsional backlash (W):
- Unlock lock collars (1) and (2) and knock
them off.
- Slacken off hub (3).
- Loosen bolts (4).
- Adjust the torsional backlash (W) by relocat-
ing shaft (5) in the bearings and, if required,
by removing or adding shims (6).
- Check the contact pattern of the tooth flanks
with engineer's blue.
- Fix lock collars (1) and (2) by blows and
secure them.
- Bolt down hub (3).
- Tighten bolts (4).
Rub solid grease on bevel gears (7) and (8) and
apply some multi-purpose grease.
9 Multi-purpose grease, e.g.:
CLAAS AGRIGREASE EP 2,
Part no. 00 0147 437 0
Fill lids (9) with 450 g of multi-purpose grease
each.
10, 11 7 Nm
M
A
= Tightening torque
Pos. Designation Dimensions Remarks
W Adjustment dimension (tor-
sional backlash)
0.3-0.5mm
