Nitrogen Generator NiGen HF - NiGen LCMS
7
For the HF-1 the maximum flow of outlet compressed air is 14 Nl/min.
3.2.3.
Compressed air supply, specifications
not applicable to
NiGen HF-1 and NiGen LCMS 40-1
(***) for further details on the air quality, see the specifications for Class 1-4-1,
ISO 8573-1
Pressure
minimum 8.5 bar 120 psi
maximum 10 bar 145 psi
Flow rate
NiGen HF-0 36 Nl/min 36 slpm
NiGen LCMS 40-0 100 Nl/min 100 slpm
NiGen LCMS 100 250 Nl/min 250 slpm
Particulates: maximum concentra-
tion of particles of diameter less
than 0.1 µm (***)
less than 0.1 mg/m³
Oil concentration less than 0.01 mg/m³
Humidity dewpoint under pressure less than 3°C
