Parts of the Wine Cooler
1. Interior light
2. Upper fan cover
3. Separator
4. Shelf
5. Lower fan cover
6. Leveling feet
7. Light switch
8. Hinge cover
9. Door
10. Recessed handle
The control panel
11. Control Panel Lock
12. Temperature increase, upper zone
13. Temperature decrease, upper zone
14. LCD display screen
15. Temperature increase, lower zone
16. Temperature decrease, lower zone
17. C/F display switch
Before installing, remove exterior and interior packing and wipe outside thoroughly with a soft dry cloth and the inside with
a damp cloth.
LOCATION OF THE WINE COOLER
1. Position wine cooler on a strong, level floor.
2. Allow 5 inches (12.7cm) of space between the back of the wine cooler and any adjacent wall and at least 0.8 inches
(2 cm) of space at each side to allow air to circulate freely around the cabinet.
3. Avoid direct sunlight and heat. Heat sources will cause higher electricity consumption.
4. Adjust legs as needed to ensure appliance is completely level.
INSTALLATION INSTRUCTIONS
PARTS OF THE WINE COOLER
