A. Insert Seat Tube Plugs #101429 into ends of the Seat Rail Tubes #104146.
B. Slide the Seat Sliders #104162 onto the Seat Rail Tubes.
C. Install the Deluxe Seat #104165 onto sliders using the OUTER holes on seat with the hardware shown.
Install the seat assembly onto the sled
using the hardware below, putting the
accessory fabric Hammock #104159
underneath.
NOTE: Hammock is packaged inside
the bag with the tent. They are
designed to be tight, so you may need
to use pliers to pull the strap far
enough to install onto bolts.
