Service
Manual
RDC605
@
ORIGINAL
SERVICE
MANUAL
This additional service manual is designed to be used
together with Model CDC605/1205/1805
Original model
CDC605/1205/1805 298-5205-00
lm SPECIFICATIONS
Common
Sampling Frequency: 44. 1kHz
Frequency Response:
5Hz to 20kHz
Dynamic Range: 95dB(1kHz)
Signal-to-Noise Ratio:
105dB(ikHz)
Wow and Flutter: Unmeasurabie
Power Supply: 14.4V(10.8V to 15.6V)
Power Consumption: Less than 1A
6DISC CHANGER
Unit Weight: 2.6kg
External Dimension(mm):
268(W) X63(H)X170(D)
12DISC CHANGER
Unit Weight: 3.3kg
External Dimension(mm):
268(W) X98(H)X170(D)
18DISC CHANGER
Unit Weight: 4.0kg
External Dimension(mm):
268(W) X133(H)X170(D)
Published by Service Dept.
6DISC COMPACT DISC CHANGER
Model CDC605
(PE-2116B,E,K)
DC605
(PE-2116C)
(S/No.305,401 ~)
12DISC COMP. DISC CHANGER
DCI205
(PE-2117B,E,K)
DCI205
(PE-2117C)
(S/No. 78,401~)
18DISC COMP. DISC CHANGER
modi COCI8OS
(PE-2118B,E,K)
(S/No. 14,451~)
Model
Model
Model
@ DESTINATION
U.S.A.
CDC605(PE-2116B-A)
RDC605(PE-2116C-A)
CDC1205(PE-2117B-A)
RDC1205(PE-2117C-A)
CDC1805(PE-2118B-A)
EUROPEAN
or.
[Model _—=SS~*dCgitaoutput |
“cDCEOaPERTIGEA) [| - |
“COGIZO5(PERTIE-A) | OS
COCTaOE(PE2ITBEA) | Ot
OTHER COUNTRY
[Model | Digitaoutput
-ODCEOsPERITEKA) | -
PODGi205(PEZII7KA) [=
Popcracs(PE2iteK-A) | Od
Digital-output
