9
English
Caution: The design and specifications of this product in order to improve its quality may be changed without notice.
7. Troubleshooting
Problem Cause Measure
No image is displayed.
Is camera connected
properly?
Check the wiring to the camera and the
camera connection.
Power does not turn on.
Is power cable
connected properly?
Check the wiring.
Is a fuse blown out?
Replace with a fuse of the same amperage
(2A).
Color is washed-out.
Operating
environment is
inappropriate.
Temperature in the car is below 0°C or over
60°C. Check to see that the temperature in
the car is appropriate (around 25°C).
8. Specifications
ITEM
SPECIFICATION
NTSC PAL
PANEL
SCREEN SIZE 5.6 INCH (14.22cm)
NUMBER OF PIXELS 320(W) x 3(RGB) x 234(H)
DOT PITCH 0.118(W) x 0.362(H) mm
BRIGHTNESS
350 cd/m
2
DISPLAY AREA 113.28(W) x 84.7(H) mm
CONTRAST RATIO 300:1
VIEW ANGLE (H/U/D) 65deg / 45deg / 65deg
POWER SUPPLY
VOLTAGE DC 12V - 24V
CURRENT 550mA (DC 12V, MONITOR SET ONLY)
REAR INPUT POWER DC 12V - 24V
INPUT SYSTEM AUTO (NTSC/PAL)
FREQUENCY
HORIZONTAL 15.734 KHz 15.625 KHz
VERTICAL 60Hz 50Hz
OSD DISPLAY 7 LANGUAGE
USER CONTROLS POWER, MODE, MENU, UP, DOWN
OPERATING TEMPERATURE -10°C ~ + 60°C
STORAGE TEMPERATURE -20°C ~ + 70°C
DIMENSION (W x H x D) 163(W) x 112(H) x 30(D)
WEIGHT 0.3Kg
ACCESSORIES
MONITOR CABLE ASS’Y·····································1
STAND ASS’Y·······················································1
CJ-5600E.book 9 ページ ２００７年２月７日 水曜日 午前９時２５分
