-11-
CX501/CX501B/CX501A
The parts for PE-3402B-B/PE-3402K-A/B
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
L210 010-3105-62
1k ohm/100MHz
R131 119-1031-15 1/10W 10k ohm R311 032-0140-89
1/10W 47k ohm F
L213 010-3407-58 4.7uH J R132 119-3321-15 1/10W 3.3k ohm R312 032-0140-89
1/10W 47k ohm F
L214 010-2198-87 82NH R133 032-0140-56
1/10W 12k ohm F
R313 119-1021-15 1/10W 1k ohm
L302 010-3105-62
1k ohm/100MHz
R134 119-2241-15
1/10W 220k ohm
R314 119-1021-15 1/10W 1k ohm
L303 010-3104-54
600 ohm/100MHz
R135 032-0215-59
1/10W 3.9k ohm(F)
R315 119-0000-05
1/10W 0 ohm JW
Q101 125-9017-92 UMD3N-TR R136 119-1031-15 1/10W 10k ohm R316 032-0140-89
1/10W 47k ohm F
Q102 103-2394-00 2SD2394 R137 119-1041-15 1/10W 100k ohm R317 032-0140-89
1/10W 47k ohm F
Q104 190-1576-00 2SA1576A R138 119-2241-15 1/10W 220k ohm R318 119-1031-15 1/10W 10k ohm
Q105 125-2027-92 DTC124EUA R139 119-5621-15 1/10W 5.6k ohm R319 119-1031-15 1/10W 10k ohm
Q106 125-3015-90 3CG1298 R14 119-1541-15 1/10W 150k ohm R320 119-1031-15 1/10W 10k ohm
Q109 125-2027-91 DTC114EUA R140 119-2231-15 1/10W 22k ohm R321 119-1031-15 1/10W 10k ohm
Q110 125-0021-92 DTA124EUA R141 032-0140-52
1/10W 33k ohm F
R322 032-0140-89
1/10W 47k ohm F
Q111 125-4024-90 3DG3875 R142 032-0215-58
1/10W 24k ohm(F)
R323 119-5631-15 1/10W 56k ohm
Q112 125-2041-93 RT1N241M R143 032-0140-80
1/10W 18k ohm F
R324 119-5631-15 1/10W 56k ohm
Q113 125-4024-90 3DG3875 R144 119-4731-15 1/10W 47k ohm R325 032-0140-89
1/10W 47k ohm F
Q114 190-1576-00 2SA1576A R145 116-1521-15 1/4W 1.5k ohm R326 119-3311-15 1/10W 330 ohm
Q115 131-1260-00 2SB1260 R146 119-4731-15 1/10W 47k ohm R327 119-5631-15 1/10W 56k ohm
Q116 125-2027-92 DTC124EUA R147 119-4731-15 1/10W 47k ohm R328 119-5631-15 1/10W 56k ohm
Q117 125-0021-95
DTA143ZUA-T106
R148 116-1521-15 1/4W 1.5k ohm R329 119-1011-15 1/10W 100 ohm
Q118 125-2027-92 DTC124EUA R149 116-4721-15 1/4W 4.7k ohm R330 119-1011-15 1/10W 100 ohm
Q119 125-0021-95
DTA143ZUA-T106
R150 119-1031-15 1/10W 10k ohm R331 119-1011-15 1/10W 100 ohm
Q120 190-1576-00 2SA1576A R151 119-6831-15 1/10W 68k ohm R332 119-1011-15 1/10W 100 ohm
Q122 125-2027-92 DTC124EUA R152 119-4721-15 1/10W 4.7k ohm R333 119-1011-15 1/10W 100 ohm
Q123 131-1260-00 2SB1260 R153 119-1031-15 1/10W 10k ohm R334 119-1011-15 1/10W 100 ohm
Q124 125-2041-93 RT1N241M R171 119-6831-15 1/10W 68k ohm R337 119-0000-05
1/10W 0 ohm JW
Q401 198-3018-00 2SK3018 R172 119-4731-15 1/10W 47k ohm R338 119-0000-05
1/10W 0 ohm JW
Q403 192-4081-00 2SC4081 R174 119-1021-15 1/10W 1k ohm R358 119-3311-15 1/10W 330 ohm
Q404 125-2027-95 DTC143ZU R181 119-0000-05
1/10W 0 ohm JW
R359 119-3311-15 1/10W 330 ohm
Q405 125-0021-95
DTA143ZUA-T106
R184 119-0000-05
1/10W 0 ohm JW
R363 119-1011-15 1/10W 100 ohm
Q406 125-2198-90 KRC110S R187 116-1521-15 1/4W 1.5k ohm R364 119-1021-15 1/10W 1k ohm
Q409 125-4012-90 KTD1304 R188 119-1031-15 1/10W 10k ohm R365 119-1021-15 1/10W 1k ohm
Q410 125-4012-90 KTD1304 R193 119-4721-15 1/10W 4.7k ohm R369 119-1031-15 1/10W 10k ohm
Q411 125-4012-90 KTD1304 R194 119-0000-05
1/10W 0 ohm JW
R370 119-1031-15 1/10W 10k ohm
Q412 125-4012-90 KTD1304 R195 119-0000-05
1/10W 0 ohm JW
R371 119-4731-15 1/10W 47k ohm
Q413 125-2027-95 DTC143ZU R196 119-4721-15 1/10W 4.7k ohm R375 119-2221-15 1/10W 2.2k ohm
Q417 192-4081-00 2SC4081 R197 119-1041-15 1/10W 100k ohm R378 119-1031-15 1/10W 10k ohm
R101 116-6811-15 1/4W 680 ohm R199 119-1031-15 1/10W 10k ohm R379 119-1031-15 1/10W 10k ohm
R102 116-6811-15 1/4W 680 ohm R200 119-1041-15 1/10W 100k ohm R404 119-4721-15 1/10W 4.7k ohm
R103 119-0000-05
1/10W 0 ohm JW
R201 119-4741-15 1/10W 470k ohm R406 119-1021-15 1/10W 1k ohm
R104 119-1031-15 1/10W 10k ohm R202 119-4741-15 1/10W 470k ohm R407 119-8221-15 1/10W 8.2k ohm
R105 119-1041-15
1/10W 100k ohm
R203 119-1011-15 1/10W 100 ohm R408 119-1021-15 1/10W 1k ohm
R106 119-1031-15 1/10W 10k ohm R204 119-0000-05
1/10W 0 ohm JW
R409 119-2231-15 1/10W 22k ohm
R107 119-1811-15 1/10W 180 ohm R206 119-0000-05
1/10W 0 ohm JW
R411 119-4711-15 1/10W 470 ohm
R108 119-4721-15
1/10W 4.7k ohm
R207 119-0000-05
1/10W 0 ohm JW
R412 119-1031-15 1/10W 10k ohm
R109 119-1811-15 1/10W 180 ohm R208 119-4721-15 1/10W 4.7k ohm R415 119-2231-15 1/10W 22k ohm
R110 119-1031-15 1/10W 10k ohm R209 116-2201-15 1/4W 22 ohm R416 119-2231-15 1/10W 22k ohm
R111 119-1031-15 1/10W 10k ohm R210 119-1011-15 1/10W 100 ohm R417 119-2231-15 1/10W 22k ohm
R112 119-2221-15
1/10W 2.2k ohm
R211 119-1011-15 1/10W 100 ohm R418 119-2231-15 1/10W 22k ohm
R113 032-0140-54
1/10W 22k ohm F
R229 119-0000-05
1/10W 0 ohm JW
R420 119-3311-15 1/10W 330 ohm
R114 119-1031-15 1/10W 10k ohm R235 119-0000-05
1/10W 0 ohm JW
R421 119-3311-15 1/10W 330 ohm
R115 032-0140-54
1/10W 22k ohm F
R272 119-0000-05
1/10W 0 ohm JW
R422 119-3311-15 1/10W 330 ohm
R116 119-5641-15
1/10W 560k ohm
R274 119-0000-05
1/10W 0 ohm JW
R424 119-3311-15 1/10W 330 ohm
R118 119-4721-15
1/10W 4.7k ohm
R275 119-0000-05
1/10W 0 ohm JW
R426 119-1021-15 1/10W 1k ohm
R12 033-0000-05 1/10W 0 ohm R276 119-0000-05
1/10W 0 ohm JW
R427 119-1021-15 1/10W 1k ohm
R120 119-4731-15 1/10W 47k ohm R277 119-0000-05
1/10W 0 ohm JW
R428 119-1031-15 1/10W 10k ohm
R121 119-1031-15 1/10W 10k ohm R3 032-0140-70
1/10W 1.8k ohm F
R429 116-4721-15 1/4W 4.7k ohm
R122 119-1031-15 1/10W 10k ohm R301 119-1041-15 1/10W 100k ohm R430 119-6831-15 1/10W 68k ohm
R123 119-1811-15 1/10W 180 ohm R302 119-1041-15 1/10W 100k ohm R431 119-1041-15 1/10W 100k ohm
R124 119-1031-15 1/10W 10k ohm R303 119-4721-15 1/10W 4.7k ohm R445 119-4731-15 1/10W 47k ohm
R126 119-2221-15
1/10W 2.2k ohm
R304 119-4721-15 1/10W 4.7k ohm SUP202 060-0122-20
DSP-141N-S00B
R127 119-1031-15 1/10W 10k ohm R305 119-1021-15 1/10W 1k ohm T401 009-9006-60 CHOKE 0.23mH
R128 119-2231-15 1/10W 22k ohm R306 119-1021-15 1/10W 1k ohm X101 061-1056-00 32.768kHz
R129 119-1031-15 1/10W 10k ohm R307 119-1021-15 1/10W 1k ohm X202 061-3031-00 4.00MHz
R13 119-5631-15 1/10W 56k ohm R308 032-0140-89
1/10W 47k ohm F
PWB 039-3740-00 PWB
(
WITHOUT
R130 119-1031-15 1/10W 10k ohm R309 032-0140-89
1/10W 47k ohm F
COMPONENT
)
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
C248 187-1073-35 16V 100uF R176 119-0000-05 1/10W 0 ohm JW R185 119-1031-15 1/10W 10k ohm
R173 119-1031-15 1/10W 10k ohm R177 119-0000-05 1/10W 0 ohm JW R186 119-1031-15 1/10W 10k ohm
R175 119-0000-05
1/10W 0 ohm JW
R178 119-0000-05 1/10W 0 ohm JW R279 119-0000-05
1/10W 0 ohm JW
