-3-
CX501/CX501B/CX501A
CAUTION
Use of controls, adjustments, or performance of procedures other
than those specified herein, may result in hazardous radiation ex-
posure. The compact disc player should not be adjusted or repaired
by anyone except properly qualified service personnel.
Bottom view of PE-3402B-A
ERROR DISPLAYS
If an error occurs, one of the following displays is displayed. Take the measures described below to eliminate the problem.
Error Display Cause Measure
A CD is loaded upside-down inside the CD deck
and does not play.
Eject the disc then reload it properly.
ERROR 6
ERROR 7
(iPod mode)
The connected iPod is not recognized.
Disconnect and reconnect the iPod.
ERROR 7 Overcurrent detection.
Disconnect the devices and reconnect. If the devices
are still not recognized, try replacing with a different
devices.
ERROR 7 Do not support the HUB devices. Do not use the HUB devices.
* If an error display other than the ones described above appears, press the reset button.
*
iPhone can also be connected to this system and "iPod" appearing in this manual should be referred to as "iPod/iPhone".
A CD is caught inside the CD deck and is not
ejected.
This is a failure of CD deck's mechanism.
ERROR 2
ERROR 3 A CD cannot be played due to scratches, etc. Replace with a non-scratched, non-warped disc.
CD/MP3/
WMA
USB/iPod
COMPONENTS
PE-3402B-A/B/PE-3402K-A/B
1
1
1
8
8
1
8
2
1
1. Source unit
2. Extension lead
3.Parts bag
3-1. Screw(M5x8)
3-2. Machine Screw(M5x8)
3-3. Finisher(PE-3402B-A/
PE-3402K-A/B)
3-4. Spacer
3-5. Double face
4. Remote control unit(PE-3402B-A)
(including battery CR2025)
854-6487-50
716-0496-51
714-5008-4B
383-0591-00
340-1581-00
347-3913-20
RCB-176-600
CX501
PE-3402B
MADE IN CHINA
276-0793-00
XXXXXXX
FCC ID: WY2PE3402BA
B017472
IC: 419E-CX501
Bluetooth QD ID:
11-2. Actuator
The actuator has a powerful magnetic circuit. If a magnetic
material is put close to it. Its characteristics will change.
Ensure that not foreign substances enter through the ventila-
tion slots in the cover.
11-3. Cleaning the lens
Dust on the optical lens affects performance.
To clean the lens, apply a small amount of isopropyl alcohol
to lens paper and wipe the lens gently.
To Next Page
