Clarion DRZ9255 User Manual

DRZ9255
HX-D2
- 4 -
Red
AUX INPUT-1
Right
HIGH
Right
To external amplifier
HIGH
Left
MID/FRONT
Right
MID/FRONT
Left
LOW/REAR
Right
LOW/REAR
Left
Subwoofer
Right
Subwoofer
Left
To external unit
AUX INPUT-1
Left
AUX INPUT-2
Right
AUX INPUT-2
Left
Antenna input
Digital input/output
CeNET input
16-Pin Connector Extension Lead 1.5m
Brown wire(phone mute lead)
Yellow wire(Bus power lead)
Red wire(Power lead)
Blue/White wire(Amplifier turn-on lead)
Orange/White wire(Illumination lead)
Blue wire(Auto antenna lead)
Fuse(3A)
Connect to cellular
phone mute lead.
Connect directly to
battery.
Accessory +12V
Connect to remote turn-on lead of amplifier.
Connect it to the car supply terminal for the antenna.
Connect to the car power supply terminal for illumination.
CeNET cable
10-Pin Connector
Fuse(5A)
Black wire(Ground lead)1.5m
Yellow wire(Memory back-up lead)3.5m
Fuse(10A)
Connect to vehicle chassis ground.
Connect the terminal on the main power cord to
the car battery(+) terminal.
Source unit
DC-DC Converter
Terminal Cover
Place the terminal cover on the terminals
to prevent a short circuit.
Terminal Cover
Optical digital cable
White
Red
White
Red
White
Red
White
Red
White
Red
Black
Black
White
WIRE CONNECTIONS
BLOCK DIAGRAM
Audio line sction
CD
Mechanism
IC903
Digital
Interface
Receiver
IC915
Sampling
-rate
Converter
IC913
Digital
Signal
Processor
IC918
S-RAM
DIGITAL DIGITAL DIGITAL DIGITAL
IC909
䌾IC911
24bit
D/A
Converter
ANALOG
ANALOG ANALOG ANALOG
IC401
䌾IC406
I/V
Converter
IC407
䌾IC410
Low-pass
Filter
IC418
䌾IC421
High-quality
Electrical
Volume
8ch Line-out
Hi
Mid
Low
Sub-woofer
IC250
DC/DC
Converter
+
-
15V
