Clarion PU-2325A User Manual

- 11 -
PU-2294A/B
PU-2325A
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
X100 061-3013-00 4.33MHz
X100 061-3013-50 4.33MHz
X101 061-1066-00 7.2MHz
X101 061-1066-50 7.2MHz
X401 061-3031-00 4.00MHz
X801 061-1081-50 12MHz
Switch PWB section(B2)
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
C101 178-1032-78 0.01μF
C102 178-6812-78 680pF
C103 178-1022-78 1000pF
C104 178-1022-78 1000pF
D101 001-0535-00 MA729
D102 001-0535-00 MA729
IC101 051-6013-10 LC75854E
J101 074-1151-18 18P
LCD101 379-1155-41 LCD(PU-2294A/PU-
2325A)
LCD101 379-1155-40 LCD(PU-2294B)
PL101 017-0454-01 14V40mA(PU-
2294A)
PL101 017-0454-02 14V40mA(PU-
2294B)
PL101 017-0454-03 14V40mA(PU-
2325A)
PL102 017-0454-01 14V40mA(PU-
2294A)
PL102 017-0454-02 14V40mA(PU-
2294B)
PL102 017-0454-03 14V40mA(PU-
2325A)
PL103 017-0454-01 14V40mA(PU-
2294A)
PL103 017-0454-02 14V40mA(PU-
2294B)
PL103 017-0454-03 14V40mA(PU-
2325A)
PL104 017-0454-01 14V40mA(PU-
2294A)
PL104 017-0454-02 14V40mA(PU-
2294B)
PL104 017-0454-03 14V40mA(PU-
2325A)
PL105 017-0454-01 14V40mA(PU-
2294A)
PL105 017-0454-02 14V40mA(PU-
2294B)
PL105 017-0454-03 14V40mA(PU-
2325A)
PL106 017-0455-00 9V65mA
PL107 017-0455-00 9V65mA
R101 117-1031-10 1/10W 10kΩ
R102 117-6831-10 1/10W 68kΩ
R103 117-4721-10 1/10W 4.7kΩ
R104 117-4721-10 1/10W 4.7kΩ
S101 013-3741-11 SKQCAE
S102 013-3741-11 SKQCAE
S103 013-3741-11 SKQCAE
S104 013-3741-11 SKQCAE
S105 013-3741-11 SKQCAE
S106 013-3741-11 SKQCAE
S107 013-3741-11 SKQCAE
S108 013-3741-11 SKQCAE
S109 013-3741-11 SKQCAE
S110 013-3741-11 SKQCAE
S111 013-3741-11 SKQCAE
S112 013-3741-11 SKQCAE
S113 013-3741-11 SKQCAE
S114 013-3741-11 SKQCAE
S115 013-3741-11 SKQCAE
S116 013-3741-11 SKQCAE
S117 013-3741-11 SKQCAE
S118 013-3741-11 SKQCAE
VR101 016-0010-13 EC11B15244
ISO PWB section(B3)
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
D1 001-0334-30 RL202
F1 060-0057-56 FUSE 10A
J1 074-1159-02 OUTLET SOCKET
P1 076-0324-10 10P
P2 076-0324-14 14P
T1 009-9006-60 0.23mH
CD mech PWB section(CD mechanism)(B4)
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
C1 183-1073-12 6.3V100μF
C2 183-4763-11 6.3V47μF
C3 178-1042-78 0.1μF
C4 176-2201-00 22pF CH
C5 176-1801-00 18pF CH
C6 176-1801-00 18pF CH
C7 176-8201-00 82pF CH
C8 178-1042-78 0.1μF
C9 178-2242-78 0.22μF
C10 178-2242-78 0.22μF
C11 176-4701-00 47pF CH
C12 178-1532-78 0.015μF
C13 178-1032-78 0.01μF
C14 178-2722-78 2700pF
C15 178-4722-78 4700pF
C16 176-1201-00 12pF CH
C17 178-4712-78 470pF
C18 178-4712-78 470pF
C19 178-4732-78 0.047μF
C20 178-4732-78 0.047μF
C21 178-4732-78 0.047μF
C22 178-4732-78 0.047μF
C23 178-1032-78 0.01μF
C25 042-0505-01 10V22μF
C26 178-1042-78 0.1μF
C27 178-1042-78 0.1μF
C29 178-1042-78 0.1μF
C30 178-1042-78 0.1μF
C31 178-1032-78 0.01μF
C32 178-1032-78 0.01μF
C33 178-1042-78 0.1μF
C34 176-1501-00 15pF CH
C35 176-1501-00 15pF CH
C38 178-1022-78 1000pF
C39 178-1042-78 0.1μF
C40 178-1042-78 0.1μF
C41 183-1073-12 6.3V100μF
C43 183-1073-12 6.3V100μF
C44 183-4763-11 6.3V47μF
C45 183-1073-12 6.3V100μF
C46 178-1032-78 0.01μF
C47 178-1042-78 0.1μF
C48 178-1032-78 0.01μF
C49 176-6801-00 68pF CH
C51 178-1032-78 0.01μF
C52 178-1032-78 0.01μF
C54 183-4763-11 6.3V47μF
C55 178-1042-78 0.1μF
C56 178-1042-78 0.1μF
C58 178-1042-78 0.1μF
C59 178-2222-78 2200pF
D1 001-0563-00 GL380
D2 001-0563-00 GL380
D3 001-0563-00 GL380
D4 001-0330-00 1SS119
IC1 051-5704-00 TA2096FN
IC2 051-6342-00 TC9462F
IC3 051-6026-08 TA2058F
IC4 051-6027-00 BA6283N
L1 010-2155-03 10μH
L3 010-2199-74 10μH J
Q1 101-1237-50 2SB1237QR
Q2 102-2712-00 2SC2712
R1 117-1011-10 1/10W 100Ω
R2 117-1841-10 1/10W 180kΩ
R3 117-1841-10 1/10W 180kΩ
R4 117-2201-10 1/10W 22Ω
R5 117-8231-10 1/10W 82kΩ
R6 117-1041-10 1/10W 100kΩ
R7 117-1041-10 1/10W 100kΩ
R8 117-1031-10 1/10W 10kΩ
R9 117-2221-10 1/10W 2.2kΩ
R10 117-1031-10 1/10W 10kΩ
R12 117-1031-10 1/10W 10kΩ
R13 117-4731-10 1/10W 47kΩ
R15 117-4741-10 1/10W 470kΩ
R17 117-3331-10 1/10W 33kΩ
R18 117-3311-10 1/10W 330Ω
R19 117-3321-10 1/10W 3.3kΩ
R20 117-1031-10 1/10W 10kΩ
R21 117-3321-10 1/10W 3.3kΩ
R22 117-3321-10 1/10W 3.3kΩ
R23 117-3321-10 1/10W 3.3kΩ
R24 117-3321-10 1/10W 3.3kΩ
R26 117-1041-10 1/10W 100kΩ
R27 117-4711-10 1/10W 470Ω
R28 117-2211-10 1/10W 220Ω
R29 117-2211-10 1/10W 220Ω
R30 117-4721-10 1/10W 4.7kΩ
R34 111-2711-91 1/4WS 270Ω
R40 117-3321-10 1/10W 3.3kΩ
X1 061-3051-00 16.92MHz
