Clark C15-35 D - Instrument Pod

3-4 Instrument Pod
Instrument Pod
1. Coolant Temperature
Gauge
2. Fuel Gauge
3. Transaxle Oil Temperature
4. Hydraulic Oil Filter
(Optional)
5. Engine Oil Pressure
6. Engine Check
7. Alternator Charging Status
8. Service Icon
9. Turn Signal
10. Hour Meter
11. Optional
12. Optional
13. Glow Plug Preheat
14. Seat Belt
15. Parking Brake
16. Work Lamp Switch
17. Rear Work Lamp Switch
18. Function Key F1/F2
19. Short Circuit Protection
