3-10 Pod Symbols and Functions
• Strobe light switch
The strobe light is operated according to the position of key
switch.
If the key switch is turned to ON position, the strobe light is
turned ON automatically.
And the strobe light is turned OFF when the key switch is
turned to OFF position.
• Function key F1/F2
Use these switches for setting the pre-set service
time. Refer to Service Icon description for use
instructions.
• Short Circuit Protection
In the event that any output circuit becomes connected
directly to ground continuously, the shorted circuit must be
turned off to prevent continuously cycling the affected switch.
The circuit that is shorted will have the pin number from the
Main Connector displayed on the LCD. The specific circuit
should continue to be shut off until the keyswitch is moved to
the off position, then returned to the on position. If the short
circuit is not removed, the shutdown sequence must be
repeated until the short is removed.
If the pin number is displayed on the LCD continuously
though the key switch was recycled, call the maintenance
staff.
