Clark C75 L - Operator Compartment

Section 3. Operator Compartment and Controls
Operator Compartment 3-3
Operator Compartment
1
2
4
5
6
7
9
8
11
16
10
12 13
3
14
18
19
20
21
15
17
(C40~80)
(seat)
1. Steering Handwheel
2. Forward / Reverse Lever
3. Brake Fluid Reservoir
4. Parking Brake Pedal
(C15-35)
5. Inching Pedal
6. Service Brake Pedal
7. Seat Adjustment Lever
8. Horn Button
9. Parking Brake Release
(C15-35)
10. Instrument Pod
11. Turn Signal Lever
12. Lift Control Lever
(C15-35)
13. Tilt Control Lever (C15-35)
14. Auxiliary Control Lever (C15-35)
15. Accelerator Pedal
16. Key Switch
17. Steer Column Tilt Lever
18. Lift Control Lever
(C40-80)
19. Tilt Control Lever (C40-80)
20. Auxiliary Control Lever (C40-80)
21. Parking brake lever (C40-80)
