2-2
Know your Tow Tractor
Dash display
LED function
The MDI-CAN has only a LED. This LED is red and lights and
blinks when an alarm is present.
Display function
Hour meter
An alpha-numeric liquid crystal display is fitted in the centre of
the unit that shows the Hours Worked. The display is backlit
(the backlight is normally on).
Alarms
The same display can also indicate the Alarm state, showing a
Code corresponding to the type of Alarm. To attract attention,
the Red LED will start blinking when an Alarm is generated.
Software version
When the Key Switch is initially closed, the display shows the
EPROM Version for a few seconds (EPXXX where XXX
represents the version): MDI-CAN and then traction controller
Eprom Version appears, each one for 2 seconds.
Simultaneously the symbol of a Monkey Wrench appears.
