Know your Tow Tractor
Battery State of Charge
The Battery's State of Charge indication is
integrated in the LCD display; it is shown by
ten notches. Each notch represents the
10% of the battery charge. As the battery
becomes discharged, the notches turn off
progressively, one after the other, in
proportion to the value of the residual
battery charge. This value, sent to the MDI-CAN by the
controller via CAN-BUS, is displayed in the Tester Menu of the
Zapi Console connected to the controller. When BATTERY
LOW alarm appears on the controller, the battery symbol
which is under the notches blinks.
Other information
Three symbols inform the operator as follows:
Turtle Symbol:
It is normally off; when it appears (fixed) it shows
activation of the “turtle” mode of the truck, in which
maximum speed and acceleration are reduced.
1.Turtle switch at steer column is activated and turtle symbol in
display is own permanent. The driver see that turtle mode is
activated.
2.The inching mode is activated by the switch in the steer
column, and the turtle symbol flash every 500ms.
3.Turtle mode and Inching active by switches at steer column.
Here should be also the turtle symbol flashing. The inching
mode has higher priority than the Turtle mode, therefore
flashing turtle symbol.
