2-22
Know your Tow Tractor
(Exchange with crane)
5. If the truck is fitted with a
weather enclosure, remove
the cover at the opening.
6. Remove the battery retainer.
7. In the event of a battery
change with a hoisting gear,
the lift should be vertical to
ensure that the battery tray
is not squeezed. Hooks
shall be attached in such a
way that they cannot fall on to the battery cells when the
hoisting gear is slack. Make sure that the chains and
safety hooks are checked and have sufficient load carrying
capacity
8. When lifting the battery in and out, be careful not to dam-
age the battery box by hitting the trucks chassis.
9. Place the battery carefully at the designated recharging
place.
10. Remove the recharged battery and install in reverse order.
11. The Tow Tractor should only be restarted when the
retainer, cables, connections, and covers have been
returned to their normal operating condition.
