2-23
Know your Tow Tractor
Fuses
• The main fuses are located
on the control unit.
• Replace faulty fuses only with
fuses of the same amperage.
• If a fuse blows frequently,
there is a fault in the electrical
system. To rectify the fault,
contact your CLARK dealer.
Fuses are located under floor plate.
The fuse ratings are clearly visible on the fuses.
Never replace a faulty fuse with one of a higher rating.
If a fuse persistently fails, there is a fault in the electrical
system. You can contact your CLARK dealer with
confidence to have the faults rectified.
CTX40-70
F1 Key switch 10 AMP
F2 DC-DC 10 AMP
F3 Head Lamp 5 AMP
F4 Flasher 10 AMP
F5 Turn Signal Lamp 5 AMP
F6 Brake Lamp 5 AMP
F7 Back Alarm 5 AMP
F8 Horn 10 AMP
F9 DC-DC (OPT) 5 AMP
F10 DC-DC (OPT) 5 AMP
Spare1 5 AMP
Spare2 10 AMP
