Section 1. Gene
ral Safety Rules
Grades, Ramp
s, Slopes
, and lnclines
1-1
1
Grades, Ramp
s, Slopes, and lnclines
WARNING
!
Never turn on a grade, either loaded or unloaded.
Unloaded
Forks Downgrade
Loaded
Forks Upgrade
22
24
