TMX 12-25 9-3
Section 9. Specifications
Truck Weights (with TSU and minimum battery weight)
Battery Capacity Range
36V Battery
48V Battery
Battery (fully charged): 1.275 SG (specific gravity)
[1.310 Exide Load Hog]
Discharged: 1.140 SG (specific gravity)
Gross Vehicle
Weight (kg [lbs])
Empty Vehicle
Weight (kg [lbs])
Loaded Drive
Axle (kg [lbs])
Empty Drive
Axle (kg [lbs])
TMX 12 4418 [9749] 3288 [7249] 3947 [8701] 1866 [4114]
TMX 15s 4947 [10908] 3587 [9708] 4352 [9594] 1855 [4090]
TMX 15 4953 [10921] 3593 [7921] 4443 [9796] 2091 [4610]
TMX 17 5357 [11805] 3767 [8305] 4907 [10819] 2163 [4769]
TMX 20 5881 [12964] 4066 [8964] 5303 [11692] 2167 [4777]
TMX 25 6848 [15093] 4578 [10093] 6078 [13401] 2158 [4758]
Battery Compartment Cells Plates
Ah @ 6-hour
Rate
kWh
13.75 in (349 mm) 18 11 600-775 20.9-27.0
20.50 in (520 mm) 18 17 800-1240 27.7-43.0
25.00 in (635 mm) 18 21 1000-1550 34.7-53.8
Battery Compartment Cells Plates
Ah @ 6-hour
Rate
kWh
13.75 in (349 mm) 24 7 375-465 17.3-21.6
20.50 in (520 mm) 24 11 625-775 29.0-36.0
25.00 in (635 mm) 24 15 875-1085 40.6-50.2
