8-2 GTS20-33
GTS20-33
CLARK products and specifications are subject to improvements and
changes without notice or obligation.
Model Designation - Rated Load Capacity
Note: Rated capacity applies when using standard upright.
[GTS20-30 : 3195mm. GTS33 : 3165mm MFH]
Engine
Cooling System
Automotive type crossflow radiator.
Cooling system pressure (radiator cap): 88 kPa nominal, 12.8psi
Thermostat: Diesel & LPG, 82°C (180°F), fully open 95°C (203°F)
Powershift Transmission
GTS20 2000 kg @500mm load center [4409 lbs @20in]
GTS25 2500 kg @500mm load center [5511 lbs @20in]
GTS30 3000 kg @500mm load center [6613 lbs @20in]
GTS33 3300 kg @500mm load center [7275 lbs @20in]
Diesel
Diesel LPG LPG
Model :
Yanmar
4TNE98
Yanmar
4TNE94L
PSI
4G64
HMC
THETA 2.4
Cylinders : 4 4 4 4
Displacement
cubic inches : 202 186 143 143
liters : 3.3 3.0 2.3 2.3
Idle RPM : 850 810 700 750
Rated RPM : 2300 2200 2650 2650
Rated kW : 44.3 34.3 51.6 52.5
Speed : 1 Forward / 1 Reverse
Overall Ratios : FWD/REV 1:1 (Diesel)
1.23:1 (LPG)
Convertor Stall Ratio : 2.87:1
