3-6 Pod Symbols and Functions
5. Gauges and indicators
• Coolant temperature gauge
• Fuel gauge
It displays the remaining fuel level in
fuel tank.
• Transmission oil temperature
Indicates that the Transmission oil
temperature is excessive. If the light is on,
shut down the truck and service it. The
truck will go into shut down mode after the
light flashes for 30 seconds. (the buzzer
sounds)
• Engine oil pressure
Indicates engine oil pressure is too low. If
the light is on, shut down the truck and
service it. The truck will go into shut down
mode after the light flashes for 30
seconds.(the buzzer sounds)
If during operation, while engine is running, oil pressure switch
closes to ground, the buzzer will sound immediately.
After 5 seconds, the engine will shutdown. The function that
has caused the shutdown will flash the corresponding icon
until the key is returned to the off position.
• LPG truck lamp
This symbol displays when the LPG truck.
50
90
130
0
1/2
4/4
