Clarke 07170A - Handle Assembly Parts List

1 920056 Nut, 6-32 E.S.N.A. Nylock 4 4 2 2
2 980621 Washer, Ext. Tooth Lock 1 1 1 1
3 962727 Screw, 8-32X1/2 3 3 3 3
4 40943A Cord, Adapter 1 1 1 1
5 11344A Speed Select, Wire Asm. 1 1
6 29912A Handle, Lower Polished 1 1
7 39871A Lens, Transparent Polycarbonate 1 1 1 1
8 61856A Plate, Switch 1 1 1 1
9 47365A Switch, Rocker 1 1
10 40947A LED Power Regulator 1 1
11 29915A Handle, Polished 1 1
12 40948A Switch, 16A, 115V 60 Hz Coil 1 1 1 1
13 40265A Tape, Thermally Conductive 1 1
14 40945A LED Board and Wiring Asm. 1 1
15 11343A Control Switch Wire, Asm. 1 1 1 1
16 43401A Housing Connector 4 4 2 2
17 80324A Screw, M5-.8X16 Btn Hd 6 6 6 6
18 85313C Screw, PHMS 6-32X3/8 4 4
19 40946A Transformer Asm. 10:1 1 1
20 85833A 10-32X3/8 HW Type 23 1 1 1 1
21 61855A Plate, Support 1 1 1 1
22 41079A Terminal Junction 1/4"X2 Tabs 2 2
23 962738 Screw, 6-32X5/8" P.H. 2 2
24 29913A Handle, Lower Charcoal, Grey 1 1
25 39868A Handle 1 1
26 71468A Label, CAS 1 1 1 1
28# 71468A Insulation 2.10 Sq. X .015 1 1 1 1
29# 56380216 Decal Power Tool Cautionary Marking 1111
30# 77094A Label Ground Symbol 1 1 1 1
[ ] = Not Shown
# = New or revised since last update
Ref. Part No. Description Qty.
07170A 07176A 07175A 07180A
Model CE7 Pro, SE7 Pro, CE7 Pro+ & SE7 Pro+
Handle Assembly Parts List
Models
Clarke
®
American Sanders Operator's Manual (EN) - CE 7 Pro, SE7 Pro, CE7 Pro+, SE7 Pro+ - FORM NO. 71376A - 41 -
revised 10/10
