Clarke BARREL User Manual

12
Fig 5: Horizontal register plate
with top flue connection
Fig 6: Horizontal register plate
with optional vertical rear flue
connection
A non-combustible register plate
minimum 1.5 mm thick should be fitted
to all installations between the flue and
the building structure. It’s suitability and
fit should be checked by a qualified
stove installation engineer against the
current Building Regulations “J”.
Fig 7
