PARTS LIST
6RSC 6RWC 6RL 8RSC 8RWC 8RL
6RR 6RRW
No. Description Part No. Qty Qty Qty Part No. Qty Qty Qty
1 Case Motor HT6R001 1 1 1 HT8R001 1 1 1
2 Stator HT6R002 1 1 1 HT8R002 1 1 1
3 Rotor Shaft HT6R003 1 1 1 HT8R003 1 1 1
4 Circlip HT6R004 2 2 2 HT8R004 n/a n/a n/a
5 Bearing HT6R005 2 2 2 HT8R005 2 2 2
6 End Bell HT6R006 2 2 2 HT8R006 2 2 2
7 Base Motor HT6R007 1 1 n/a HT8R007 1 1 n/a
7A Base Motor HT6R007A n/a n/a 1 HT8R007A n/a n/a 1
8 Switch Base Plate HT6R008 1 1 1 HT8R008 1 1 1
- Switch Base Screw HT6R008A 2 2 2 HT8R008A 2 2 2
- Switch Base Star Washer HT6R008B 2 2 2 HT8R008B 2 2 2
9 Switch Assembly HT6R009 1 1 1 HT8R009 1 1 1
10 Capacitor HT6R010 1 1 1 HT8R010 1 1 1
11 Capacitor Clamp HT6R011 1 1 1 HT8R011 1 1 1
12 Cable HT6R012 1 1 1 HT8R012 1 1 1
13 Plate Securing HT6R013 1 1 1 HT8R0013 1 1 1
- Plate Securing Screw HT6R013A 2 2 2 HT8R013A 2 2 2
14 Grommet HT6R014 1 1 1 HT8R014 1 1 1
15 Grommet HT6R015 1 1 1 HT8R015 1 1 1
16 Rubber Foot HT6R016 4 4 4 HT8R016 4 4 4
17 Screw HT6R017 4 4 4 HT8R017 4 4 4
18 Bolt Hex 6mm HT6R018 2 2 2 HT8R018 2 2 2
18a Spring washer 6mm HT6R018A 2 2 2 HT8R018A 2 2 2
18b Bolt Hex 5mm HT6R018B 1 1 1 HT8R018B 1 1 1
18c Spring washer 5mm HT6R018C 1 1 1 HT8R018C 1 1 1
19 Pan Head Screw HT6R019 8 8 8 HT8R019 8 8 8
20 Flat Washer HT6R020 8 8 8 HT8R020 8 8 8
20a Spring washer HT6R020A 8 8 8 HT8R020A 8 8 8
21 Base Cover HT6R021 1 1 1 HT8R021 1 1 1
22 Wheel Cover Outer Right HT6R022 1 1 1 HT8R022 1 1 1
23 Wheel Nut Right Hand HT6R023 1 1 1 HT8R023 1 1 1
24 Wheel Flange Outer HT6R024 2 2 2 HT8R024 2 2 2
25 Wire Wheel HT6R025 n/a 1 n/a HT8R025 n/a 1 n/a
25a G. Wheel - Coarse 6501088 1 n/a 1 6501110 1 n/a 1
25b G. Wheel - Medium 6501089 n/a 1 n/a 6501024 n/a 1 n/a
25c G. Wheel - Fine 6501135 1 n/a 1 6501130 1 n/a 1
26 Wheel Flange Inner HT6R026 2 2 2 HT8R026 2 2 2
27 Wheel Cover HT6R027 2 2 2 HT8R027 2 2 2
28 Wheel Cover Inner Right HT6R028 1 2 2 HT8R028 1 1 1
29 Tool Rest Right Hand HT6R029 1 1 1 HT8R029 1 1 1
30 Flat Washer HT6R030 4 4 4 HT8R030 4 4 4
30a Spring washer HT6R030A 4 4 4 HT8R030A 4 4 4
31 Screw Hex HT6R031 4 4 4 HT8E031 4 4 4
32 Bolt HT6R032 6 6 6 HT8R032 6 6 6
33 Flat Washer HT6R033 12 12 12 HTR033 12 12 12
