Clarke CMD300 - Parts List

18
Item Description Qty Part No Item Description Qty Part No
1 Base 1 SGCMD300001
2 X-axis feed screw 1 SGCMD300002
2-1 Key 4xl6 2 SGCMD300003
4 Dial 2 SGCMD300004
5 Hand wheel 2 SGCMD300005
6 Nut M8 2 SGCMD300006
7 Knob 2 SGCMD300007
8 Screw M8 x 55 2 SGCMD300008
9 Cap Screw M6x8 8 SGCMD300009
10 Plate (1) 1 SGCMD300010
11 Dust guard cover 1 SGCMD300011
12 Plate (2) 2 SGCMD300012
13 Ball bearing 8200 2 SGCMD300013
14 Washer 2 SGCMD300014
15 Nut M8 4 SGCMD300015
16 Y-axis scale 1 SGCMD300016
17 Cap screw M6 x 16 4 SGCMD300017
18 Y-axis bearing seat 1 SGCMD300018
19 Work table 1 SGCMD300019
20 Y-axis feed screw 1 SGCMD300020
21 End cover I SGCMD300021
22 Screw M6 x 10 2 SGCMD300022
23 Y-axis screw nut 1 SGCMD300023
24 Holding plate (3) 1 SGCMD300024
25 Dust guard cover 1 SGCMD300025
26 Screw seat 1 SGCMD300026
27 Cap screw M6 x 16 2 SGCMD300027
28 Set screw M6 x 22 6 SGCMD300028
29 Nut M6 13 SGCMD300029
30 Handle 3 SGCMD300030
31 Screw M6 x 10 2 SGCMD300031
32 Pointer 1 SGCMD300032
33 Screw M6 x 8 1 SGCMD300033
34 X-axis Jib Strip 1 SGCMD300034
35 Saddle 1 SGCMD300035
36 Y-axis Jib Strip 1 GCMS3000036
37 X-axis screw nut 3 SGCMD300037
38 Cap screw M6 x 25 2 SGCMD300038
39 Vertical Post seat 1 SGCMD300039
39-1 Shaft 1 SGCMD3000391
39-2 Key 8 x 12 1 SGCMD3000392
40 Spring washer 10 3 SGCMD300040
40-1 Washer 10 3 SGCMD3000401
41 Cap screw Ml0 x 30 3 SGCMD300041
42 Pointer 2 SGCMD300042
43 Set screw M6 x 22 7 SGCMD300043
44 Scale 1 SGCMD300044
45 Jib Strip 1 SGCMD300045
46 Gear rack 1 SGCMD300046
47 Cap screw M6 x 12 4 SGCMD300047
48 Label 1 SGCMD300048
49 Spindle box 1 SGCMD300049
50 Pinion 1 SGCMD300050
51 Key 4x25 1 SGCMD300051
52 Bevel gear 1 SGCMD300052
53 Retaining ring 12 1 SGCMD300053
54 Ball 1 SGCMD300054
55 Spring 0.8 x 0.8 x 10 1 SGCMD300055
56 Screw 6 x 8 1 SGCMD300056
57 Handle Hub 1 SGCMD300057
58 Operating lever 3 SGCMD300058
59 Handle 3 SGCMD300059
60 Cap screw M8 x 25 4 SGCMD300060
61 Pointer 1 SGCMD300061
62 Cap screw M6 x 25 1 SGCMD300062
63 Spindle box seat 1 SGCMD300063
64 Jib Strip 1 SGCMD300064
65 Limit block 1 SGCMD300065
66 Jib Strip 1 SGCMD300066
67 Scale 1 SGCMD300067
68 Vertical Post 1 SGCMD300068
69 Electric box I SGCMD300069
70 Lock nut M24 1 SGCMD300070
71 Large washer 1 SGCMD300071
72 Connecting strut 1 SGCMD300072
78
Key 5x5x40 1 SGCMD300078
79 Spindle 1 SGCMD300079
80 Transmmision gear 1 SGCMD300080
81 Support Block 1 SGCMD300081
82 Screw 2 SGCMD300082
83 Pin 4x78 1 SGCMD300083
84 Worm 1 SGCMD300084
Parts List
