THE HANDLE AND OPERATING PEDAL
The handle is secured to the frame using the pin provided.
The operating pedal should be slid into place and secured using the M8x12
bolt supplied.
OPERATION
NOTE: The operator must be able to watch the lift and the load during all
movements.
RAISING THE LOAD
1. Position the saddle between the
wheels of the motorcycle, as near
to the centre of gravity as
possible.
2. Pump the operating pedal until
the saddle makes light contact
with the motorcycle frame, then
assess where packing may be
required to ensure the motorcycle
is well supported and stable.
