PARTS LIST
MAIN UNIT
HARDWARE BOX
ITEM
N
O
DESCRIPTION
PART
NUMBER
ITEM
N
O
DESCRIPTION
PART
NUMBER
A Base HTCML5A L Pump Spring HTCML5L
B Link HTCML5B M Lock Rear Castor Assembly HTCML5M
C Lift Saddle HTCML5C N Height Lock Bar HTCML5N
D Height Lock Release HTCML5D O Front Wheel Assembly HTCML5O
E Connecting Rod HTCML5E P Loops HTCML5P
F T - Handle HTCML5F Q Clip HTCML5Q
G Locking Screw HTCML5G R Height Lock Springs HTCML5R
H Return Spring HTCML5H S Lock Position Ridge HTCML5S
I Hydraulic Ram HTCML5I T Rubber Pads HTCML5T
J Foot Pedal HTCML5J U Oil Fill Plug HTCML5U
KRelease Pedal HTCML5K
1Spring Nut
Sold as 1 Kit
HTCML5KIT
2Nut M8
3Cotter Pin
4Bolt M8 x 12
5Bolt M8 x 25
6Washer
7Bolt M6 x 15
8Rachet Straps
