Please note that the details and specifications contained herein are correct at the time of going to
print. However CLARKE International reserve the right to change specifications at any time without
prior notice. Always consult the machines data plate.
Please read these instructions carefully before operating the tool
Thank you for purchasing this
CLARKE
Milling/Drilling Machine.
Before using the device, please read this manual thoroughly and carefully follow all
instructions given. This is for your own safety and that of others around you, and is also to
help you achieve a long and trouble free service from your new machine.
CLARKE GUARANTEE
This CLARKE product is guaranteed against faulty manufacture for a period
of 12 months from the date of purchase. Please keep your receipt as proof
of purchase.
This guarantee is invalid if the product is found to have been abused or
tampered with in any way, or not used for the purpose for which it was
intended.
Faulty goods should be returned to their place of purchase, no product can
be returned to us without prior permission.
This guarantee does not affect your statutory rights.
PARTS & SERVICE TEL: 020 8988 7400
or e-mail as follows:
PARTS: Parts@clarkeinternational.com
SERVICE: Service@clarkeinternational.com
-
20
-
Item Part No Description Qty
91 CC1225091 Bolt 2
92 CC1225092 Graduation Plate 1
93 CC1225093 Screw 1
94 CC1225094 Screw 1
95 CC1225095 Small Handle Wheel 1
96 CC1225096 Nut 1
97 CC1225097 Graduation Plate 1
98 CC1225098 Washer 1
99 CC1225099 Feed Base 1
100 CC1225100 Nut 1
101 CC1225101 Washer 1
102 CC1225102 Ball Bearing 1
103 CC1225103 Retaining Ring 1
104 CC1225104 Bolt 1
105 CC1225105 Washer 1
106 CC1225106 Hexagon Nut 1
107 CC1225107 Spindle Sleeve 1
108 CC1225108 Drift 1
109 CC1225109 Ball Bearing 1
110 CC1225110 Spindle 1
111 CC1225111 Ball Bearing 1
112 CC1225112 Micro Switch Base 1
113 CC1225113 Screw 4
114 CC1225114 Nut 2
115 CC1225115 Micro Switch 1
116 CC1225116 Screw 2
117 CC1225117 Screw 4
118 CC1225118 Link 1
119 CC1225119 Nut 1
120 CC1225120 Screw 2
121 CC1225121 Fixed Link 1
122 CC1225122 Screw 2
123 CC1225123 Shaft 1
124 CC1225124 Sleeve 1
125 CC1225125 Protecting Cover 1
126 CC1225126 Protecting Plate 1
127 CC1225127 Guide Screw 1
128 CC1225128 Screw 1
129 CC1225129 Column Lid 1
130 CC1225130 Screw 1
131 CC1225131 Link 2
132 CC1225132 Column 2
133 CC1225133 Ladder Rack 1
134 CC1225134 Bolt 4
135 CC1225135 Washer 4
136 CC1225136 Protection Board Strip 1
To Next Page
