Clarke PC60 - Reversing Motor and Pilot Motor Applications; PARTS LIST

8
Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com
• When reversing the motor, ensure that the motor has stopped fully
before doing so.
• For some applications of small motors or motors of unusual magnetic
characteristics, it may be necessary to provide a pilot motor to obtain a
balance of phases. Generally the pilot motor should be a 2 pole (2800
rpm) motor and as a general guide should be at least twice as big as
the motor to be driven.
If necessary, consult a qualified technician.
PARTS LIST
No Description Suppliers No
1 Front Frame EM21690425
2 D.38 Knob for Red Switch + Indicator EM04600268
3 Green Pilot-Lamp 220 EM22610006
4 Circuit Breaker 32A EM22210012
5 Ammeter 30S FS60 EM22600051
6 Capacitor MKM 8mf 450V 30x78 EM22315026
6 Capacitor MKM 16mf 450V 45x80 EM22315028
6 Capacitor MKM 25mf 450V 45x103 EM22315030
6 Capacitor MKM 50mf 450V 50x128 EM22315032
7 Relay LY2 24VDC EM22225318
8 Capacitor 4.7mf-63V 5x11 P-2 EM26000005
8 W10 Rectifier EM26014005
9 Plastic Handle EM21600030
10 Cover Panel EM33705461
11 Switch I6A Sch 1602 EM22205021
12 Orange Pilot Lamp EM22610013
13 Double Pole Black Switch EM22200043
14 PVC Input Cable 3x2,5 M.2,5 EM20220020
15 Cable Clamp D.10 + Screw EM04600234
16 CEE 16A 380V 3pH Socket + Panel Earth EM22105067
17 Front Panel EM33710373
18 Back Panel EM33715123
19 Capacitor Support EM33640257
