Classen PRO HSC18A5 - Main Frame Assembly

21
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
PRO
SOD CUTTER
MAIN FRAME ASSEMBLY
FIGURE 1
1 4172001 S-MAIN BODY HSC18 1
2 C400236.17 BUMPER, 5.5HP 1
C400237.17 BUMPER, 8 HP
3 4172005 S-SHIELD,BELT, MAIN 1
(INCLUDES ITEMS 43 & 45)
4 4172008 S-GUARD,CHAIN, HYDROSTAT 1
(INCLUDES ITEM 44)
5 4172383.7 GUARD, FINGER HSC185 1
6 4171193.7 FORK-SWIVEL WHEEL 1
7 C100017 TIRE & WHEEL ASSY (9X350X4) 1
8 90-1048 BOLT-5/8-11 X 6 NC 1
9 64163-64 WSHR 1.015X1.500X14GA 5
10 C400251 HANDLE, NEUTRAL 1
11 C100021 BUSHING, BRASS 2
12 C300203 L-PIN, SWIVEL WHEEL 1
13 C100601 SPRING, SC SWIVEL WHEEL 1
14 64221-1 E-RING 25MM/1.000 1
15 C100501 PIN, 3/8" VLIER 1
16 C500129 NUT, 3/8-16 7
17 C100010 PULLEY-IDLER 1
18 38010-2A IDLER PULLEY 1
19 64221-07 E-RING .375 1
20 C500091 BOLT, 3/8-16 X 2 2
21 C500042 WASHER, 3/8 FLAT 7
22 C500140 BOLT, 5/16-18 X 3/4 7
23 C500130 WASHER, 3/8 LOCK 5
24 C500115 WASHER, 5/16 LOCK 8
25 64268-03 NUT-3/8-16 NYLOCK 1
26 C400443.7 ARM, BLADE CLUTCH HYDRO 1
27 C500043 BOLT, 3/8-16 X 1 2
28 C500154 BOLT, 3/8-16 X 2-3/4 1
29 C500134 BOLT, 3/8-16 X 1-1/4 4
30 C500016 PIN, 5/32" X 1-1/4" COTTER 1
31 4173099.7 CHAIN GUARD SCHV 1
32 C500219 BOLT, 5/16 X 5 1
33 C500101 NUT, 5/16-18 3
34 C500001 GREASE FITTING, 1/4 X 28 2
35 C100617 PIN-ROLL 1
36 64229-16 NUT-NYLON LOCK 5/8-11 1
37 4171963 DECAL, CLASSEN FLAT BLACK 1
38 C100559 DECAL-LUBRICATE 1
39 4171824 LABEL - HSC18 2
40 4171825 LABEL - CLASSEN PRO 1
41 C500083 WASHER-5/16 FLAT 1
42* C100490 HYDRO MANUAL ROLL DECAL 1
43 2000577 LABEL WARNING 1
44 4168760 LABEL WARNING - HAND PINCH 1
45 C100504 DECAL-SPARK ARRESTOR 1
* NOT ILLUSTRATED
