Classen PRO HSC18A5 - Power Train Assembly

27
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
PRO
SOD CUTTER
POWER TRAIN ASSEMBLY
FIGURE 4
1 C100493 SPROCKET, #40x54 w/ HUB 1
2 4175021 S-WHEEL, 8-5/8 DRIVE 4
3 C100005 ENGINE HONDA 5.5HP 1
C100114 ENGINE-HONDA 8 HP
4 C300204 SPACER, 3/4" JACK SHAFT 1
5 C200056 S-SPROCKET W/ SHAFT 1
6 C100491 B55 V-BELT FOR 5.5HP 1
C100503 B58 V-BELT FOR 8 HP
7 C500004 KEY, 1/4 x 1 SQUARE 3
8 C500011 KEY, 3/16 SQUARE X 1 2
9 C100339 RESERVOIR, HYDROSTAT 1
10 C500259 SET SCREW, 5/16-24 x 3/8 1
11 C400249-1 CLUTCH ARM, SCH 1
12 4171228.7 SHIFTER ARM, SCH 1
13 C100028 PULLEY W/HUB & BOLTS 1
14 C300001 SPACER, DRIVE SHAFT 1
15 C500029 BOLT, 1/4-20 x 3/4 4
16 C200001 SPROCKET W/HUB, DRIVE SHAFT 1
17 4171051 SHAFT, 12" DRIVE 1
18 C100013 BEARING W/ ECCENTRIC, 3/4" 2
19 C600003 SC-18 1" ECENTRIC SHAFT 1
20 C200002 PULLEY W/HUB & BOLTS, 6" 1
21 C100004 BEARING W/ECCENTRIC, 1" 4
22 C100025 LINK, #40 CONNECTING 2
23 C500158 BOLT, 1/2-13 x 3-1/2 8
24 C100043 SPROCKET, #40x17x1/2 IDLER 1
25 C100494 #40 X 76 ROLLER & CON LINK 1
26 C100513 B38 V-BELT 1
27 C500001 GREASE FITTING, 1/4 x 28 4
28 64164-51 KEY-SQ 1/4 X 1-1/4 ROUNDED 2
29 C500181 KEY, 1/4 x 1-1/2 SQUARE 1
30 C500147 BOLT-5/16-18 X 1-1/2 4
USED ON 5.5HP MODELS
C500079 BOLT-3/8-16X1-3/4 4
USED ON 8HP MODELS
31 C500115 WASHER, 5/16 LOCK 6
32 C500101 NUT, 5/16-18 6
33 C500083 WASHER, 5/16 FLAT 4
34 C500131 NUT, 1/2-13 LOCK 1
35 C100433 RING, 1/2" SNAP 1
36 C200054 S-SHEAVE, 2BK62H BUSHING 1
37 C100311 HYDROSTAT 1
38 C500168 BOLT, 5-16-18 x 4-1/2 2
39 C500074 BOLT, 5/16-18 X 1-3/4 2
40 C200044 SPROCKET, 13 TOOTH 1
41 C500135 BOLT, 1/2-13 x 21/2 1
42 C100495 #40 X 50 ROLLERS & CON LINK 1
43 C700035.7 HUB, ECCENTRIC 2
44 C500136 NUT,1/4-20 4
45 C500137 WASHER, 1/4 LOCK 4
46* 4161646 PLUG-OIL 1
USED ON 8HP ONLY
47 C500147 BOLT, 5/16-18 x 1-1/2 4
48 C500034 WASHER, 1/2 FLAT 18
49 C500174 BOLT, 1/2-13 x 1-3/4 8
50 C500006 WASHER, 1/2 LOCK 16
51 C500106 NUT, 1/2-13 16
52 C500115 WASHER, 5/16 LOCK 4
USED ON 5.5HP MODELS
C500130 WASHER, 3/8 LOCK 4
USED ON 8HP MODELS
53 C500101 NUT-5/16-18 4
USED ON 5.5HP MODELS
C500129 NUT, 3/8-16 4
USED ON 8HP MODELS
54 C100027 SPRING, THROTTLE 1
55 C100501 SPRING, PLUNGER 1
56 64163-67 WSHR-.516X1X12GA 8
57* B222522 DEFLECTOR, EXHAUST 1
USED ON 5.5HP ONLY
58 C500036 KEY-7MM SQUARE 1
59 C500083 WASHER, 5/16 FLAT 4
USED ON 5.5 HP
C500042 WASHER, 3/8 FLAT
USED ON 8 HP
60 C100244 WIRE SWIVEL 1
61 C500003 KEY-1/4 X 7/8 HALF MOON 2
*NOT ILLUSTRATED
