23
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
PRO
SOD CUTTER
HANDLE ASSEMBLY
FIGURE 2
1 4172001 S-MAIN BODY HSC18 1
2 4172003 S-MAIN HANDLE HSC18 1
(INCLUDES ITEMS 34-36)
3 4171190.7 WLDMNT-HANDLE, ENGAGEMENT 1
4 4171914.7 LINKAGE-ENGAGEMENT RH 1
5 4171191.7 WLDMNT-HANDLE, CONTROL 1
6 4171192 WLDMNT-HYDRO LINK 1
7 4171228.7 ARM-SHIFTER 1
8 4176912.7 DAMPENER-ISOLATION 1
9 4171230.7 PLATE-SPEED SELECTOR 1
10 4171194.7 BRKT-MOUNTING, RUBBER 1
11 C400443.7 ARM, BLADE CLUTCH HYDRO 1
12 C100486 FINGER THROTTLE & CABLE 1
13 C100546 MOUNTS, VIBRATION 4
14 C100635 RUBBER BUSHING, TAPERED 2
15 4171701.7 BUSHING - 1/2ID X 1-1/2L 1
16 C100018 GRIP, L.H. HANDLE 2
17 4176911-02 GRIP-1X.125X4 YELLOW 1
18 C500042 WASHER, 3/8 FLAT 14
19 C500130 WASHER, 3/8 LOCK 9
20 C500129 NUT, 3/8-16 15
21 C500026 YOKE, 3/8 CLEVIS 1
22 64123-328 BOLT-HEX 3/8-16 X 4-1/4 1
23 90-0826 BOLT 1/2-13 X 3-1/4 NC 1
24 C500115 WASHER, 5/16 LOCK 5
25 C500101 NUT, 5/16-18 7
26 C500134 BOLT, 3/8-16 X 1-1/4 9
27 C500083 WASHER, 5/16 FLAT 2
28 C500131 NUT, 1/2-13 LOCK 1
29 C500041 NUT, 3/8-16 LOCK 2
30 C500163 BLT-CRG 5/16-18 X 3/4 2
31 C500065 SPRING-SPEED STOP 1
32 64268-08 NUT-FL NYLON LOCK 5/16-18 2
33 64221-07 E-RING .375 1
34 4171618 LABEL-THROTTLE HSC18 1
35 4171619 LABEL-BLADE ENGAGE 1
36 4176911-01 GRIP-1X.125X4 GREEN 1
37 C400249-1 CLUTCH ARM SCHV 1
38 C500133 BOLT-5/16-18 X 1 1
39 C500025 NUT-3/8-24 1
40 C500029 BOLT-1/4-20 X 34 1
41 C100034 SRING-1/4-20 1
42 C500136 NUT-1/4-20 1
43 02-CP0508 COTTER PIN 5/32 X 1 ZP 1
44 64188-03 S-PIN CLEVIS 3/8X1-1/8 1
45 C500088 WASHER-1/4 FLAT 2
46 C500074 BOLT-5/16-18 X 1-3/4 2
47 4176931 LABEL-HSC18 OPERATION 1
* NOT ILLUSTRATED
