Classen SC-18AHD - Specifications

SPECIFICATIONS
SC-18A/5.5 & SC-18A/8.0
ENGINE
Model SC18A/5.5.........................4 cycle 5.5 HP
Honda
Model GX160
9.9 cu-in (163 cc)
Model SC18A/8.0.........................4 cycle 8 HP
Honda
Model GX270
16.5 cu-in (270 cc)
Starter....................................................Recoil
Governor........3400 RPM ± 200 RPM, no load
Clutch...........spring loaded belt tightener type
REDUCTION
Engine to blade..................................3.03 to1
Engine to drive wheels......................57.2 to 1
WHEELS:
Drive.....................8” (203 mm) Dia. w/knobby
tread vulcanized to hub
Rear...........................8 x 1.75 (203 X 45mm)
semi-pneumatic tires
CUTTING WIDTH:
SC-18.........................................................18”
REDUCTION BOX
Lubrication...........................................20W50
Capacity..................................31/2Pints(1.7L)
CUTTING DEPTH.........................up to 2-1/2”
BLADE PITCH
Hand lever adjustment...........variable 0° to 9°
BLADE SPEED................1188 RPM @ 3400
engine RPM
DIMENSIONS
Width.............23” - For all, except SC-24 - 25”
Length........................................................59”
Height.........................................................35”
Wheel Base................................................22”
WEIGHT
Dry Weights
SC-18A/5.5..........................................328 Ibs.
SC-18A/8.0..........................................352 Ibs.
16
SC-18A
ENGINE
Model SC18AHD ................................ 4 cycle 5.5 HP
Honda Model GX160 9.9 cu-in (163 cc)
Model SC18AHD ................................ 4 cycle 5.5 HP
Kohler Model CH255 10.8 cu-in (17 cc)
Starter .............................................................. Recoil
Governor........3400 RPM ± 200 RPM, no load
Clutch...........spring loaded belt tightener type
REDUCTION
Engine to blade ........................................ 3.03 to1
Engine to drive wheels ............................ 57.2 to 1
WHEELS:
Drive ...........................8” (203 mm) Dia. w/knobby
tread vulcanized to hub
Rear ................................... 8 x 1.75 (203 X 45mm)
semi-pneumatic tires
CUTTING WIDTH:
SC-18 ...............................................................18”
REDUCTION BOX
Lubrication .................................................. 20W50
Capacity ........................................ 31/2Pints(1.7L)
CUTTING DEPTH .................................. up to 2-1/2”
BLADE PITCH
Hand lever adjustment .................variable 0° to 9°
BLADE SPEED ............................1188 RPM @ 3400
engine RPM
DIMENSIONS
Width ................. 23” - For all, except SC-24 - 25”
Length ..............................................................59”
Height ...............................................................35”
Wheel Base ......................................................22”
WEIGHT
Dry Weights
SC-18AHD .................................................328 Ibs.
SC-18AHD/5.5K ........................................328 Ibs.
SPECIFICATIONS
SC-18A/5.5 & SC-18A/8.0
ENGINE
Model SC18A/5.5.........................4 cycle 5.5 HP
Honda
Model GX160
9.9 cu-in (163 cc)
Model SC18A/8.0.........................4 cycle 8 HP
Honda
Model GX270
16.5 cu-in (270 cc)
Starter....................................................Recoil
Governor........3400 RPM ± 200 RPM, no load
Clutch...........spring loaded belt tightener type
REDUCTION
Engine to blade..................................3.03 to1
Engine to drive wheels......................57.2 to 1
WHEELS:
Drive.....................8” (203 mm) Dia. w/knobby
tread vulcanized to hub
Rear...........................8 x 1.75 (203 X 45mm)
semi-pneumatic tires
CUTTING WIDTH:
SC-18.........................................................18”
REDUCTION BOX
Lubrication...........................................20W50
Capacity..................................31/2Pints(1.7L)
CUTTING DEPTH.........................up to 2-1/2”
BLADE PITCH
Hand lever adjustment...........variable 0° to 9°
BLADE SPEED................1188 RPM @ 3400
engine RPM
DIMENSIONS
Width.............23” - For all, except SC-24 - 25”
Length........................................................59”
Height.........................................................35”
Wheel Base................................................22”
WEIGHT
Dry Weights
SC-18A/5.5..........................................328 Ibs.
SC-18A/8.0..........................................352 Ibs.
16
