ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
HANDLE ASSEMBLY
FIGURE 2
1 4176911-02 GRIP-1x.125x4 YELLOW 1
2 C100018 GRIP, L.H. HANDLE 2
3 C100132 DECAL, CUTTER BLADE 1
4 C100133 DECAL, SLOW / FAST 1
5 C100134 DECAL, WHEEL DRIVE 1
6 C100486 THROTTLE CONTROL & CABLE 1
7 C300138.17 BRACE, HANDLE 1
8 4172184 S-HANDLE, MAIN 1
INCLUDES ITEMS 3-5 & 62
9 C400007.17 ARM, CUTTING BLADE ADJ 1
10 C400008.17 HANDLE, ENGAGEMENT 2
11 C400074.17 ARM, WHEEL DRIVE ADJ 1
12 C400110.17 PIVOT ASSEMBLY 1
13 C500001 GREASE FITTING, 1/4 x 28 1
14 C500019 SPRING, SMALL HANDLE 2
15 C500025 NUT, 3/8-24 2
16 C500026 YOKE, 3/8 CLEVIS 2
17 C500041 NUT, 3/8-16 LOCK 11
18 C500042 WASHER, 3/8” FLAT 3
19 C500043 BOLT, 3/8-16 X 1 7
20 C500074 BOLT, 5/16-18 X 1-3/4 2
21 C500101 NUT, 5/16-18 6
22 C500115 WASHER, 5/16 LOCK 10
23 C500129 NUT, 3/8-16 6
24 C500130 WASHER, 3/8 LOCK 6
25 C500133 BOLT, 5/16-18 x 1 2
26 C500134 BOLT, 3/8-16 x 1-1/4 2
27 C500137 WASHER, 1/4 LOCK 3
28 C500139 NUT, 1/4-20 LOCK 4
29 C500146 BOLT, 3/8-16 x 1-1/2 2
30 C500154 BOLT, 3/8-16 x 2-1/2 2
31 64123-310 BLT-HEX 1/4-20X2 PLT FLTHR+ 2
32 C100001 WASHER, 3/4 NYLON 8
33 C100002 SEAL 8
34 C100003 BEARING 4
35 C100007 GRIP, RUBBER 2
36 C100016.7 BLADE, 18” SOD CUTTER 1
37 C200004.7 BOLT PITCH ADJUSTMENT 1
38 C200005.7 BOLT, HEIGHT ADJUSTMENT 1
39 C300039.7 PLATE, DEPTH GAUGE 1
40 C400001.7 BAR, HIEGHT ADJUSTMENT 1
41 C400238.7 1
42 4172692 1
43 C500006 4
44 C500007.7 1
45 C500034 10
46 C500088 1
47 C500106 4
48 C500131 2
49 C500241 2
50 C500249 2
51 C500152 2
52 C600001 4
53 4179027
PITCH ADJUSTMENT BAR
KNOB-PLASTIC
WASHER, 1/2 LOCK
NUT, 1/2 HANDLE
WASHER, 1/2 FLAT
WASHER, 1/4” FLAT
NUT, 1/2-13
NUT, 1/2-13 LOCK
Bolt, 1/2-13 x 1
BOLT, 1/2 X1 FINE THREAD
BOlt, 1/2-13 X 2-3/4
STEEL SLEEVE
S- ARM, ECCENTRIC-incl.
items 13,32,33,34,52,65,66
2
54 4172017 S-ARM, BLADE 2
55 C500136 NUT, 1/4-20 4
56 C500296 BOLT, 1/4-20 CRG 1
57 C500068 NUT, 1/4-20 NYLOC 1
58* 4164033 LABEL-CHF VERT 2
59 4175303 BLT-HEX 5/16-24X1 FL THD 6
60 64025-51 NUT-5/16-24 6
61 4176911-01 GRIP-1x.125x4 GREEN 1
62 4176440 LABEL, SC-18 1
63 C500272 WASHER-1/2” EXT LOCK 2
64 C400412.7 WSHR-STEEL ENHANCED 2
65 C100626 WSHR-PLASTIC 4
66 C100625 BEARING-ENHANCED 2
*NOT ILLUSTRATED
