Classen SC-18AHD - Page 23

23
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
POWER TRAIN ASSEMBLY
FIGURE 3
1 C100004 BEARING 1” PILLOW BLOCK 4
2 C100005 ENGINE, 5.5 H.P. HONDA 1
3 C100008 REDUCTION BOX 1
4 C100010 PULLEY, IDLER 2
5 C100011 V-BELT, BX31 DRIVE 2
6 C100013 BEARING 3/4” PILLOW BLOCK 2
7 C100022 PULLEY, TAPER LOCK 1
8 C100023 HUB, TAPER LOCK 1
9 C100024 V-BELT, B B56 ENGINE 5.5HP 1
10 C100025 LINK, #40 CONNECTING 1
11 C100026 V-BELT 6934 BELT 1
12 C100027 SPRING, THROTTLE 1
13 C100028 PULLEY W/ HUB & BOLTS 1
14 C100207 SHEAVE, DUAL DRIVE DBLE V 1
15 C100208 PULLEY, DRIVE DBLE IDLER 1
16 C100307 CHAIN, 58 ROLLERS 1
17 C200001 SPROCKET W/HUB, SHAFT 1
18 C200002 PULLEY W/HUB & BOLTS, 6” 1
19 C200031 PULLEY, DUAL DRIVE 5” SPLIT 1
20 C300001 SPACER, DRIVE SHAFT 1
21 C300004.7 CLIP, R.H. BELT ADJUSTMENT 1
22 C300134.7 CLIP, BELT L.H. 1
23 C200039 JACK SHAFT 1
24 C500003 KEY, 1/4 x 7/8 HALF MOON 2
25 C500004 KEY, 1/4 x 1 SQUARE 2
26 C500006 WASHER, 1/2 LOCK 17
27 C500240 KEY, 3/16 X 1 1/2 1
28 C500029 BOLT, 1/4-20 x 3/4 2
29 64163-67 WSHR-.516X1X12GA 8
30 C500042 WASHER, 3/8” FLAT 18
31 4175021 WHEEL, MOLDED 4
32 C500083 WASHER, 5/16 FLAT 8
33 C500091 BOLT, 3/8-16 x 2 2
34 C500101 NUT, 5/16-18 8
35 C500106 NUT, 1/2-13 17
36 C500115 WASHER, 5/16 LOCK 8
37 C500129 NUT, 3/8-16 11
38 C500130 WASHER, 3/8 LOCK 17
39 C500137 WASHER, 1/4 LOCK 4
40 C500136 NUT, 1/4-20 4
41 C500146 BOLT, 3/8-16 x 1-1/2 5
42 C500147 BOLT, 5/16-18 x 1-1/2 8
43 C500154 BOLT, 3/8-16 x 2-1/2 1
44 64189-15 BLT-HEX 1/4-20 X 1 2
45 C500158 BOLT, 1/2-13 x 3-1/2 8
46 C500159 BOLT, 3/8-16 X3 1
47 C500174 BOLT, 1/2-13 x 1-3/4 8
48 C500181 KEY, 1/4 x 1-1/2 SQUARE 2
49 C600003 SHAFT, ECCENTRIC 1
50 4171051 SHAFT, 12” DRIVE 1
51 4179029 S- ECCENTRIC HUB SET (INCL.
(2) HUBS AND (2) ITEM 24)
1
52* C100244 SWIVEL, WIRE 1
53 C500064 SET SCREW, 5/16-18 X 3/8 1
54 64164-51 KEY-SQ 1/4 X 1-1/4 ROUNDED 2
*NOT ILLUSTRATED
SC-18A
ITEM PART NO. DESCRIPTION QTY
1 C100004 BEARING 1” PILLOW BLOCK 4
2 C100005
102-0003-00
ENGINE, 5.5 H.P. HONDA
ENGINE, 5.5 H.P. KOHLER
1
3 C100008 REDUCTION BOX 1
4 C100010 PULLEY, IDLER 2
5 C100011 V-BELT, BX31 DRIVE 2
6 C100013 BEARING 3/4” PILLOW BLOCK 2
7 C100022 PULLEY, TAPER LOCK 1
8 C100023 HUB, TAPER LOCK 1
9 C100024 V-BELT, B B56 ENGINE 5.5HP 1
10 C100025 LINK, #40 CONNECTING 1
11 C100026 V-BELT 6934 BELT 1
12 C100027 SPRING, THROTTLE 1
13 C100028 PULLEY W/ HUB & BOLTS 1
14 C100207 SHEAVE, DUAL DRIVE DBLE V 1
15 C100208 PULLEY, DRIVE DBLE IDLER 1
16 C100307 CHAIN, 58 ROLLERS 1
17 C200001 SPROCKET W/HUB, SHAFT 1
18 C200002 PULLEY W/HUB & BOLTS, 6” 1
19 C200031 PULLEY, DUAL DRIVE 5” SPLIT 1
20 C300001 SPACER, DRIVE SHAFT 1
21 C300004.7 CLIP, R.H. BELT ADJUSTMENT 1
22 C300134.7 CLIP, BELT L.H. 1
23 C200039 JACK SHAFT 1
24 C500003 KEY, 1/4 x 7/8 HALF MOON 2
25 C500004 KEY, 1/4 x 1 SQUARE 2
26 C500006 WASHER, 1/2 LOCK 17
27 C500240 KEY, 3/16 X 1 1/2 1
28 C500029 BOLT, 1/4-20 x 3/4 2
29 64163-67 WSHR-.516X1X12GA 8
30 C500042 WASHER, 3/8” FLAT 18
31 4175021 WHEEL, MOLDED 4
32 C500083 WASHER, 5/16 FLAT 8
33 C500091 BOLT, 3/8-16 x 2 2
34 C500101 NUT, 5/16-18 8
ITEM PART NO. DESCRIPTION QTY
35 C500106 NUT, 1/2-13 17
36 C500115 WASHER, 5/16 LOCK 8
37 C500129 NUT, 3/8-16 11
38 C500130 WASHER, 3/8 LOCK 17
39 C500137 WASHER, 1/4 LOCK 4
40 C500136 NUT, 1/4-20 4
41 C500146 BOLT, 3/8-16 x 1-1/2 5
42 C500147 BOLT, 5/16-18 x 1-1/2 8
43 C500154 BOLT, 3/8-16 x 2-1/2 1
44 64189-15 BLT-HEX 1/4-20 X 1 2
45 C500158 BOLT, 1/2-13 x 3-1/2 8
46 C500159 BOLT, 3/8-16 X3 1
47 C500174 BOLT, 1/2-13 x 1-3/4 8
48 C500181 KEY, 1/4 x 1-1/2 SQUARE 2
49 C600003 SHAFT, ECCENTRIC 1
50 4171051 SHAFT, 12” DRIVE 1
51 4179029 S-ECCENTRIC HUB SET (INCL.
(2) HUBS AND (2) ITEM 24)
1
52* C100244 SWIVEL, WIRE 1
53 C500064 SET SCREW, 5/16-18 X 3/8 1
54 64164-51 KEY-SQ 1/4 X 1-1/4 ROUNDED 2
*NOT ILLUSTRATED
23
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
POWER TRAIN ASSEMBLY
FIGURE 3
1 C100004 BEARING 1” PILLOW BLOCK 4
2 C100005 ENGINE, 5.5 H.P. HONDA 1
3 C100008 REDUCTION BOX 1
4 C100010 PULLEY, IDLER 2
5 C100011 V-BELT, BX31 DRIVE 2
6 C100013 BEARING 3/4” PILLOW BLOCK 2
7 C100022 PULLEY, TAPER LOCK 1
8 C100023 HUB, TAPER LOCK 1
9 C100024 V-BELT, B B56 ENGINE 5.5HP 1
10 C100025 LINK, #40 CONNECTING 1
11 C100026 V-BELT 6934 BELT 1
12 C100027 SPRING, THROTTLE 1
13 C100028 PULLEY W/ HUB & BOLTS 1
14 C100207 SHEAVE, DUAL DRIVE DBLE V 1
15 C100208 PULLEY, DRIVE DBLE IDLER 1
16 C100307 CHAIN, 58 ROLLERS 1
17 C200001 SPROCKET W/HUB, SHAFT 1
18 C200002 PULLEY W/HUB & BOLTS, 6” 1
19 C200031 PULLEY, DUAL DRIVE 5” SPLIT 1
20 C300001 SPACER, DRIVE SHAFT 1
21 C300004.7 CLIP, R.H. BELT ADJUSTMENT 1
22 C300134.7 CLIP, BELT L.H. 1
23 C200039 JACK SHAFT 1
24 C500003 KEY, 1/4 x 7/8 HALF MOON 2
25 C500004 KEY, 1/4 x 1 SQUARE 2
26 C500006 WASHER, 1/2 LOCK 17
27 C500240 KEY, 3/16 X 1 1/2 1
28 C500029 BOLT, 1/4-20 x 3/4 2
29 64163-67 WSHR-.516X1X12GA 8
30 C500042 WASHER, 3/8” FLAT 18
31 4175021 WHEEL, MOLDED 4
32 C500083 WASHER, 5/16 FLAT 8
33 C500091 BOLT, 3/8-16 x 2 2
34 C500101 NUT, 5/16-18 8
35 C500106 NUT, 1/2-13 17
36 C500115 WASHER, 5/16 LOCK 8
37 C500129 NUT, 3/8-16 11
38 C500130 WASHER, 3/8 LOCK 17
39 C500137 WASHER, 1/4 LOCK 4
40 C500136 NUT, 1/4-20 4
41 C500146 BOLT, 3/8-16 x 1-1/2 5
42 C500147 BOLT, 5/16-18 x 1-1/2 8
43 C500154 BOLT, 3/8-16 x 2-1/2 1
44 64189-15 BLT-HEX 1/4-20 X 1 2
45 C500158 BOLT, 1/2-13 x 3-1/2 8
46 C500159 BOLT, 3/8-16 X3 1
47 C500174 BOLT, 1/2-13 x 1-3/4 8
48 C500181 KEY, 1/4 x 1-1/2 SQUARE 2
49 C600003 SHAFT, ECCENTRIC 1
50 4171051 SHAFT, 12” DRIVE 1
51 4179029 S- ECCENTRIC HUB SET (INCL.
(2) HUBS AND (2) ITEM 24)
1
52* C100244 SWIVEL, WIRE 1
53 C500064 SET SCREW, 5/16-18 X 3/8 1
54 64164-51 KEY-SQ 1/4 X 1-1/4 ROUNDED 2
*NOT ILLUSTRATED
