The chemical timer allows the following dosing to be adjusted
P1 = Detergent /
Soap pump
• Cycle rinse aid
• Cycle detergent / soap
• Initial detergent / soap
P2 = Rinse aid pump
4.2 Rinse & wash tank temperatures :
The water temperatures on ’Classic’ range of machines is none adjustable.
Temperatures
Machine type
Rinse water Wash water
Glasswashers 60°c
55°c
Dishwashers 80°c
4.3 Interlock options :
Eco1,Eco2, Eco3, H500,H700 & H750 have the following four interlock options,
all other under counter appliances do not have such options, to select such an
option remove the front lower panel, towards the centre of the machine you will
find four cables tied together, each wire with a different coloured cover (black,
green, red & white), by connecting different combinations together you will
obtain the appropriate interlock option
• Interlock removed
Will start at any temperature
All four wires disconnected from each other
• Wash tank only
Will only start if the wash tank is up to temperature
Connect the Black crimp to the White crimp
• Quick start (default setting)
Will start if the rinse tank is above 55°c
Connect the Green crimp to the White crimp
• Interlock
All tanks must be up to temperature, before a cycle will start
Connect the Red crimp to the White crimp
Page 7
