8
ASSEMBLY AND OPERATION INSTRUCTIONS
Attach high pressure hose from hose reel to the gun wand, hand tighten until
two parts are locked.
Attach desired color coded spray tip to quick - connect wand by pushing
to ensure it is clicked in securely. Insert quick – connect wand into the gun
wand, hand tighten until two parts are locked.
CaUTiOn
Placing any spray tip too close to a surface can result in permanent
damage to the surface being sprayed. Maintain at least a 24” distance
between the tip and the surface being sprayed until you have determined it
is safe to move the tip closer to the surface.
Recommendation for spray tip
usage:
Yellow
15°
Can be used to clean
concrete.
White
40°
Can be used to clean
wide areas faster than
the 15 degree nozzle.
Black
Low pressure
To apply detergent
