Page 9
HOSES AND HAND TOOL
SCHEMATIC DRAWING AND PARTS LIST
CF-3 CleanFreak Spotter
3-Gallon Carpet Spot Extractor
100 CFM / 800 Watt Motor
Drawing No. Item ID Item Description Qty. Needed
1 10-0500-I 4” Clear View Upholstery Tool 1.00
2 10-0463 Black Slip Hose Cuff - Spotter 2.00
3 50-1008 15-Foot Vacuum Hose 1-1/4” 1.00
4 10-0868 1/4” Female QD for Sniper 1.00
5 80-8007 1/4” x 15-Foot Extractor Hose 1.00
6 10-0870 1/4” Male QD 1.00
To Next Page
