Plumbing (continued)
8
Column Column Flange Bolts & Flange Washers(8 ea.) Diffuser Riser Tube Base Flange Gasket Base Flange Nuts & Washers (8ea.) Contact Column Exploded View Figure 4-4
Contact Column Installation Diagram Figure 4-3 6” Clamp Assembly Bolts, nuts & with bolt & Nut washers (2ea.) Unistrut (cut to length) Unistrut “L” Bracket Protective End cap Concrete Anchors with nuts &
washers (2ea.)
