CLEAR DESIGN BLADE BBC1 - Page 19

16
66" W RETURN OR LARGER
PARTS LIST
CODE QTY DESCRIPTION
GB3072 1
Surface 30"x72"
GB2466 1
Return Surface 24"x66"
BB3
2
Extra Long Beam
4
Lock Plate
8
Cap Screw
2
Locking Screw and Lever
BL30
2
BLADE 30" End Leg
12
Wood Screws
BL24
1
BLADE 24" End Leg
6
Wood Screws
BASB72
2
42" Support Bar*
20
Wood Screws
BFB1 2
Flat Bracket*
BCLEG 1
C-Leg
BLC1 1
Leg Connecting Bracket
*Support bars will be added to surfaces 72" and longer. Flat Brackets
will be added when attaching return to main surface.
