17
66" W RETURN OR LARGER
1 | JOIN MAIN SURFACE 30" END LEGS WITH BEAM
Insert beam tabs into leg brackets. Guide beam tabs into bracket holes,
ensuring that there is not a gap between the beam and legs.
Using a rubber mallet, hammer the beam to lock in place.
2 | BOLT DOWN BEAM-TO-LEG LOCK PLATE
Note: The beam lock plates will not fit if there is a gap between the beam
and the leg.
To Next Page
