4
54" W RETURN OR SMALLER
3 | MEASURE AND ADJUST BEAM WIDTH
Measure from end leg to end leg until you find the approximate width of the
work surface. Insert the screw through the overlapping beam slots and into
the locking screw and lever. Slightly tighten the screw. DO NOT fully
tighten. Insert beam grommet covers.
4 | SECURE MAIN SURFACE
Position surface on desk frame. Align outer sides of surface flush and parallel
with outer sides of the end legs, adjust if not flushed. Insert wood screws into leg
brackets and secure to underside of the surface.
Align Flush
Align Flush
To Next Page
