ClearStream 600DAC3 - Design Drawings and Diagrams; Clearstream System Plan View; Clearstream System Section View

DESIGN D
R
A
W
ING
CLEARSTREAM 600DAC3
SECTION
CLEARSTREAM
PLAN
CLARIFIER
DIFFUSER
EFFLUENT PUMP
PRETREATMENT
CONTROL PANEL
FLOW LINE
AIR LINE
60"
58"
3" WALL
151"
TANK
AERATION
TANK
TANK
PUMP
CONDUIT
SURGE CONTROL
WEIR AND FILTER
4" PVC
82"
AIR LIFT RETURN 3/4" PVC : MUST BE LYING ON CONCRETE - USE 45 TURNS
ACCESS COVER FOR 20" OPENING
154"
INLET
AIR LINE 3/4" PVC
20" ACCESS COVER
AIR SUPPLY DROP 3/4" PVC
6"
HIGH LEVEL ALARM FLOAT
AIRLIFT ASSEMBLY
AERATOR
AIRLIFT AIR SUPPLY
1" TREATED EFFLUENT DISCHARGE
GRADE
AERATOR
AIRLIFT SUPPLY LINE
10"
AIRLIFT INLET
3/4" FLEX PIPE
3/4" FLEX PIPE
CSUV1 optional
for Std 40 and 245
applications.
Required for Std 350
applications.
20" ACCESS COVER
CSUV1 DISINFECTION
PUMP HEAD DISCHARGE ASSEMBLY
HIGH LEVEL ALARM FLOAT
RETURN TO PRETREAT
12" ACCESS COVER
CS103ET6 AERATOR
9 of 12
