CleaverBrooks CB780 User Manual

CB780/CB784 RELAY MODULES
13 32-00207—01
Fig. 8. Wiring multiple Keyboard Display Modules.
L1
(HOT)
L2
1
1
1
A B
A B
C (GND)
+13 VDC
RESET
C (GND)
+13 VDC
RESET
1
23
4
5
1
23
4
5
MOMENTARY
PUSH BUTTON
SWITCH
833-2727 KEYBOARD DISPLAY MODULE
(MOUNTED ON CB 780/CB 784 RELAY MODULE)
13 VDC
POWER SUPPLY
833-2727 REMOTE KEYBOARD DISPLAY MODULE
THREE WIRE SHIELDED CABLE MAY BE REQUIRED. TWO 120
OHM TERMINATING RESISTORS ARE REQUIRED FOR
CONNECTIONS OVER 100 FEET. CABLE SHIELD MUST BE
TERMINATED TO EARTH GROUND AT BOTH ENDS. IF SHIELDED
CABLE IS NOT USED, TWISTED PAIR WIRE MUST BE USED.
M27263A
832-1693
120 OHM
RESISTOR
832-1693
120 OHM
RESISTOR
2
2
TERMINALS OF 833-2760 5-WIRE CONNECTOR (PROVIDED
SEPARATELY).
