Introduction
1 - 4 External Locator - Top View with LCD Panel Open
1.Introduction
External Locator - Top View with LCD Panel Open
Figure 1
Top View
1. PC Camera
2. *PC Camera LED
*When the PC
camera is in use,
the LED will be
illuminated.
3. Built-In Array
Microphone
4. LCD
5. Power Button
6. Keyboard
7. Touchpad &
Buttons
8. Fingerprint
Reader (Optional)
2 1
8
7
6
4
5
33
