Introduction
Specifications 1 - 3
1.Introduction
Pointing Device
Built-in Touchpad (with Microsoft PTP Multi Gesture & Scroll-
ing Functionality)
Card Reader
Embedded Multi-In-1 Card Reader
MMC (MultiMedia Card) / RS MMC
SD (Secure Digital) / Mini SD / SDHC/ SDXC
M.2 Slots
Slot 1 for Combo WLAN and Bluetooth Module
Slot 2 for SATA or PCIe Gen3 x4 SSD
Slot 3 for PCIe Gen3 x4 SSD only
Interface
One DisplayPort 1.3 over USB 3.1 Gen 2 Type-C Port
One USB 3.1 Gen 2 Type-A Port
One USB 3.0 (USB 3.1 Gen 1) Type-A Port
One USB 2.0 Port
One Mini DisplayPort 1.2
One HDMI-Out Port
One Microphone-In Jack
One 2- In-1 Audio Jack (Headphone and Microphone)
One RJ-45 LAN
Jack
One DC-In Jack
USB 3.1 Gen 2
Note that when a single USB device is plugged
in to a USB 3.1 Gen 2 port the data transfer
speed will be 10Gbps, however when two devic-
es are plugged in to both USB 3.1 Gen 2 ports,
this bandwidth will be shared between the ports.
Communication
Built-In 10/100/1000Mb Base-TX Ethernet LAN
1.0M HD PC Camera Module
WLAN/ Bluetooth M.2 Modules:
(Factory Option) Intel® Dual Band Wireless-AC 9260 Wire-
less LAN (802.11ac) + Bluetooth
(Factory Option) Intel® Dual Band Wireless-AC 9560 Wire-
less LAN (802.11ac) + Bluetooth
(Factory Option) Intel® Dual Band Wireless-AC 9462 Wire-
less LAN (802.11ac) + Bluetooth
(Factory Option) Qualcomm® Atheros Killer™ Wireless-AC
1550i Wireless LAN (802.11ac) + Bluetooth
Environmental Spec
Temperature
Operating: 5
°C - 35°C
Non-Operating: -20°C - 60°C
Relative Humidity
Operating: 20% - 80%
Non-Operating: 10% - 90%
Power
Removable 4 Cell Smart Lithium-Ion Battery Pack, 48.96WH
Full Range AC/DC Adapter
AC Input: 100 - 240V, 50 - 60Hz
DC Output: 19.5V, 9.23A (180W)
Dimensions & Weight
399.9mm (w) * 282.2mm (d) * 29.2mm (h)
2.5kg (Barebone with 48.96WH Battery)
