Clevo W251EUQ - Removing the 3.75 G Module

Disassembly
2 - 14 Removing the 3.75G Module
2.Disassembly
Removing the 3.75G Module
Figure 10
3G Module Removal
a. Disconnect the cable
and remove the screw.
b. The module will pop-up.
c. Remove the 3.75G mod-
ule.
Note: Make sure you
reconnect the antenna
cable to socket.
1. Turn off the computer, turn it over, and remove the battery (page 2 - 5) and the component bay cover (page 2 - 9).
2. Carefully disconnect the cable , then remove the screw from the module socket.
3. The 3.75G module (Figure 10b) will pop-up, and you can remove it from the computer (Figure 10c).
1
2
4
3
b.
a.
d.
1
2
3
c.

3. 3.75G Module
•1 Screw
