Clevo W650SR - External Locator - Top View with LCD Panel Open

Introduction
1 - 4 External Locator - Top View with LCD Panel Open
1.Introduction
External Locator - Top View with LCD Panel Open
Figure 1
Top View
1. PC Camera
2. Built-In
Microphone
3. *PC Camera LED
*When the PC
camera is in use,
the LED will be
illuminated in red.
4. LCD
5. LED Indicator
6. Power Button
7. Keyboard
8. Touchpad &
Buttons
5
3
4
6
1
2
7
8
Note that the Touchpad and
Buttons valid operational area
is that indicated within the red
dotted lines.
7
8
