5. OPERATING INSTRUCTIONS
Control panel
Attention: if the air conditioner is restarted immediately after shutdown in cool mode, 3min protection time
is necessary before automatic start.
: ON/OFF button; press this button to turn on or off the air conditioner.
: mode button selection; during on or timer on pressing this button can select COOL, DRY and
FAN modes. The corresponding indicator lamp to the selected mode is on.
: if the timer on or timer off is set, pressing UP or DOWN can adjust on/off time; in
running state of COOL mode or timer state, pressing UP or DOWN can adjust the set temperature; and
pressing UP and DOWN simultaneously can realize conversion between °C and °F. The corresponding
indicator lamp to the selected mode is on.
: pressing this button can select different speeds in cycle of LOW and HIGH; the corresponding
indicator lamp to the selected speed is on.
: press this button to enter timer setting state, and the indicator lamp is on.
Dual 88 display: this pattern displays the set temperature in COOL mode, and displays room temperature
in FAN and DEHUMIDIFY modes; display of °C shows current centigrade temperature, and display of °F
shows current Fahrenheit temperature.
: this indicator lamp is normally on when SLEEP state is started.
: in water full state this indicator lamp flickers with buzzer to prompt drainage.
Remote control
POWER: press this button to turn ON/OFF the air conditioner.
TIMER: press this button to set timer.
C° F°: temperature conversion button, to move from °C to °C or from °F to C°.
COOL: press this button to select COOL mode
DRY: press this button to select dehumidify mode
FAN: press this button to select ventilator mode
TEMP: press UP or DOWN to set temperature or time
HIGH: press this button to select HIGH speed
LOW: press this button to select LOW speed
